Product Summary
The TLV707 series (TLV707xx and TLV707xxP) of
low-dropout linear regulators (LDOs) are low
quiescent current devices with excellent line and load
transient performance, and are designed for
power-sensitive applications. These devices provide
a typical accuracy of 0.5%. All versions have thermal
shutdown and overcurrent protection for safety.
Furthermore, these devices are stable with an
effective output capacitance of only 0.1 μF. This
feature enables the use of cost-effective capacitors
that have higher bias voltages and temperature
derating. These devices also regulate to the specified
accuracy with no output load.
The TLV707xxP also provides an active pull-down
circuit to quickly discarge the outputs.
The TLV707 series are available in a 1-mm x 1-mm
DFN (SON) package that makes them ideal for
handheld applications.
Parametrics
TLV70718PDQNR is the nominal output voltage. For output voltages with a resolution of 100mV, two digits are used in the
ordering number; otherwise, three digits are used (for example, 18 = 1.8V, 285 = 2.85V).
P is optional; devices with P have an LDO regulator with an active output discharge.
TLV70718PDQNR is the package designator.
Z is package quantity. Use R for reel (3000 pieces), and T for tape (250 pieces).
Features
Very Low Dropout: 250 mV at 150 mA
0.5% Typical Accuracy
1.5% Accuracy over Temperature
Low IQ: 25 μA
Fixed-Output Voltage Combinations Possible
from 1.2 V to 5.0 V(1)
High PSRR:
– 70 dB at 100 Hz
– 50 dB at 1 MHz
Stable with Effective Capacitance of 0.1 μF(2)
Thermal Shutdown and Overcurrent Protection
Package: 1-mm × 1-mm DFN (SON)
See Package Option Addendum at end of this document for
complete list of available voltage options.
See Input and Output Capacitor Requirements in the
Application Information section for more details.
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 TLV70718PDQNR |
Texas Instruments |
Low Dropout (LDO) Regulators 200mA,Lo-IQ,Lo-Noise LDO Reg |
Data Sheet |
|
|
||||||||||||
| Image | Part No | Mfg | Description | |
Pricing (USD) |
Quantity | ||||||||||||
 |
TLV70012DCKR |
Texas Instruments |
Low Dropout (LDO) Regulators 200mA,Lo IQ,LDO Reg |
Data Sheet |
|
|
||||||||||||
|
TLV70012DCKT |
Texas Instruments |
Low Dropout (LDO) Regulators 200mA,Lo IQ,LDO Reg |
Data Sheet |
|
|
||||||||||||
|
TLV70012DDCR |
Texas Instruments |
Low Dropout (LDO) Regulators 200mA,Low IQ,LDO Reg |
Data Sheet |
|
|
||||||||||||
|
TLV70012DDCT |
Texas Instruments |
Low Dropout (LDO) Regulators 200mA,Low IQ,LDO Reg |
Data Sheet |
|
|
||||||||||||
|
TLV70012DSER |
Texas Instruments |
Low Dropout (LDO) Regulators 200mA Low IQ LDO Reg |
Data Sheet |
|
|
||||||||||||
|
TLV70012DSET |
Texas Instruments |
Low Dropout (LDO) Regulators 200mA Low IQ LDO Reg |
Data Sheet |
|
|
||||||||||||
